Max. core length
6000 mm
Core barrel net length with cutting shoe
6187 mm
Core barrel diameter (inside)
102 / 96 mm (liner)
Core barrel diameter (outside)
108 mm
Water depth rating
250m / 1000m (deep water)
Height
7.50 m
Basement diameter
4.60 m
Gross weight (excl. uploads)
0.85 to
Gross weight (full uploads)
1.1 to
Motor Power
4kW
Power supply (three phase AC)
380 – 440 V, 4 kVA, 50-60 Hz
Vibrating force
30 kN (7.5 kN deep water)
Vibrating frequency
28 Hz (14 Hz deep water)
Penetration
sand, gravel, till, clay, tone
Corrosion protectio
hot zinced steel / Stainless Steel SS AISI 316
Transport
dismantled in 20 foot container
